All torches are rigorously tested using computerised and automated test equipment at the design stage through to production.
All our components pass rigorous quality control checks prior to assembly.
All torches are designed to be tough and damage resistant and comply with EN 60974-7.
Torch heads lightweight and durable
• Manufactured with high temperature resistant silicone rubber insulation.
• All copper components ensure cooler running temperatures and maximum
current capacity.
Front end consumables exentensive range
• Front end consumables are manufactured to the highest specifications. and
superior performance.
Trigger switches plug and play™ technology
• Located in a neutral finger position
• 3 Different switch options to suit every application.
Cable systems
• Optimum cable performance and flexibility is guaranteed through the exclusive
use of overbraid power cables.
• Switch leads are shielded as standard to ensure minimal interference and
maximum machine protection.
A range of cable plugs are available to suit thermajority machines trigger switches plu and play™ technology
• Located in a neutral finger position
• 3 Different switch options to suit every application.
| STANDARD COLLET | STANDARD GAS LENS CUP | |||
| Stock code | Stock code | Description | Description | |
| A UB10N21 UB10N22 UB10N23 UB10N24 UB10N25 UB54N20 | A UB10N21 UB10N22 UB10N23 UB10N24 UB10N25 UB54N20 | I UB54N17
UB54N16
UB54N15
UB54N14
UB54N19 | Gas Lens Cup 5/16”/8mm Bore Gas Lens Cup 3/8”/10mm Bore Gas Lens Cup 7/16”/11mm Bore Gas Lens Cup 1/2”/13mm Bore Gas Lens Cup 1 1/16”/18mm Bore | |
| STANDARD COLLET BODY | LONG GAS LENS CUP | |||
| Stock code | Description | Stock code | Description | |
| B UB10N29 UB10N30 UB10N31 UB10N31M UB10N32 UB10N28 UB406488 | Collet Body .020”/0.5mm Bore Collet Body .040”/1.0mm Bore Collet Body 1/16”/1.6mm Bore Collet Body 5/64”/2.0mm Bore Collet Body 3/32”/2.4mm Bore Collet Body 1/8” /3.2mm Bore Collet Body 5/32”/4.0mm Bore | J UB54N17L
UB54N16L
UB54N15L
| Long Gas Lens Cup 5/16”/8mm Bore Long Gas Lens Cup 3/8”/10mm Bore Long Gas Lens Cup 7/16”/11mm Bore | |
| STANDARD CERAMIC CUP | LARGE DIAMETER GAS LENS BODY | |||
| Stock code | Description | Stock code | Description | |
| C UB10N50 UB10N49 UB10N48 UB10N47 UB10N46 UB10N45 UB10N44 | Ceramic Cup 1/4”/6mm Bore Ceramic Cup 5/16”/8mm Bore Ceramic Cup 3/8”/10mm Bore Ceramic Cup 7/16”/11mm Bore Ceramic Cup 1/2”/13mm Bore Ceramic Cup 5/8”/16mm Bore Ceramic Cup 3/4”/19mm Bore | UB45V116
UB45V64 Large
UB995795 Large
| Large Diameter Gas Lens Body 1/16”/1.6mm Bore Diameter Gas Lens Body 3/32”/2.4mm Bore Diameter Gas Lens Body 1/8”/3.2mm Bore | |
| LONG CERAMIC CUP | LARGE DIAMETER GAS LENS CUP | |||
| Stock code | Description | Stock code | Description | |
| D UB10N49L
UB10N48L
UB10N47L
| Long Ceramic Cup 5/16”/8mm Bore Long Ceramic Cup 3/8”/10mm Bore Long Ceramic Cup 7/16 “/11mm Bore | L UB57N75
UB57N74
UB53N87
| Large Diameter Gas Lens Cup 3/8”/10mm Bore Large Diameter Gas Lens Cup 1/2”/13mm Bore Large Diameter Gas Lens Cup 3/4”/19mm Bore | |
| STUBBY COLLET | STUBBY COLLET BODY | |||
| Stock code | Description | Stock code | Description | |
| E UB10N21S
UB10N22S
UB10N23S
UB10N24S
UB10N25S | Stubby Collet .020”/0.5mm Bore Stubby Collet .040”/1.0mm Bore Stubby Collet 1/16”/1.6mm Bore
Stubby Collet 3/32”/2.4mm Bore Stubby Collet 1/8”/3.2mm Bore | F UB17CB20
| Stubby Collet Body .020”-1/8”/0.5-3.2mm Bore | |
| STUBBY CERAMIC CUP | STANDARD GAS LENS BODY | |||
| Stock code | Description | Stock code | Description | |
| G UB13N08 UB13N09 UB13N10 UB13N11 UB13N12 UB13N13 | Ceramic Cup 1/4”/6mm Bore Ceramic Cup 5/16”/8mm Bore Ceramic Cup 3/8”/10mm Bore Ceramic Cup 7/16”/11mm Bore Ceramic Cup 1/2”/13mm Bore Ceramic Cup 5/8”/16mm Bore | H UB45V24
UB45V25
UB45V26
UB45V27
UB45V28
| Gas Lens Body .040”/1.0mm Bore Gas Lens Body 1/16” /1.6mm Bore Gas Lens Body 3/32”/2.4mm Bore Gas Lens Body 1/8”/3.2mm Bore Gas Lens Body 5/32”/4.0mm Bore | |
| COMPONENTS | |
| Stock code | Description |
| 1 UB18CG 2 UB18CG20 3 UB54N01 4 UB54N63 5 UBPRO18FX 6 UBPRO18 7 UB98W18 8 UBPRO57Y02 9 UBPRO57Y04 10 UBPRO1MS 11 UBPROSWL4 12 UBPROH200 13 UBPROSP 14 UBPROKJ200 15 UBPROLC 200-08 16 UBPROCO 200-40 UBPROCO 200-80 17 UBPRONC32 UBPRONC72 18 UBPROJK200 19 UBB5024 | Cup Gasket Cup Gasket (For Stubby Collet Body) Gas Lens Insulator (Use with 18CG) Large Diameter Gas Lens (Use with 18CG) Insulator Torch Head Flexible Torch Head including Cup Gasket Back Cap ‘O’ Ring Pro-Grip® Back Cap Long Pro-Grip® Back Cap Short Momentary Switch Kit (Fitted as standard) Switch Lead x 4m (12.5ft) UBPROSWL8 Switch Lead x 8m (25ft) PRO-GRIP® TIG Handle Large Screw Pack Knuckle Joint c/w Lock Nut Leather Cover x .8m (2.6ft) Complete Cover Assembly x 4m (12.5ft) Complete Cover Assembly x8m (25ft) Neoprene Cover x 3.2m (10.5ft) Neoprene Cover x 7.2m (23.6ft) Jointing Repair Kit Water Hose Clamp 9.5mm Bore
|
Torch heads lightweight and durable
• Manufactured with high temperature resistant silicone rubber insulation.
• All copper components ensure cooler running temperatures and maximum
current capacity.
Front end consumables exentensive range
• Front end consumables are manufactured to the highest specifications. and
superior performance.
Trigger switches plug and play™ technology
• Located in a neutral finger position
• 3 Different switch options to suit every application.
Cable systems
• Optimum cable performance and flexibility is guaranteed through the exclusive
use of overbraid power cables.
• Switch leads are shielded as standard to ensure minimal interference and
maximum machine protection.
A range of cable plugs are available to suit thermajority machines trigger switches plu and play™ technology
• Located in a neutral finger position
• 3 Different switch options to suit every application.
