The ADF820L comes with a substantial 95x80mm extra-large viewing area. This feature facilitates comprehensive observation of the working environment, promoting heightened safety awareness. The secure design ensures a safe working environment, while the expansive visibility significantly enhances welding efficiency.
Flip-up design - Easy lift up for grinding function, suiting welding / cutting / grinding mode.
Large view for grinding - 20 x 12 cm area, large and curved transparent grinding anti-fog lens.
Superior lens-technology - Highest optical class 1 / 1 / 1 / 1, offering best vision experience and welding efficiency.
Save-power function- Solar cell combined with replaceable battery, greatly increase service life.
High impact resistance - High tenacity shell material, passing EN175 B and ANSI Z87 + impact test under highest level.
Pivot headgear - Adjustable pivot design, well-balanced design, maximum comfort level, lock function in upright state.
Side window - Shade 5 lens on both sides, enhance surrounding vision, safer and securer.
| ADF SPECIFICATIONS | |
| OPTICAL CLASS
VIEWING AREA CARTRIDGE SIZE ARC SENSOR LIGHT STATE DARK STATE SHADE CONTROL POWER ON / OFF SENSITIVITY CONTROL UV / IR PROTECTION POWER SUPPLY
SWITCHING TIME DELAY (DARK TO LIGHT) LOW AMPERAGE TIG RATED GRINDING LOW BATTERY INDICATOR BATTERY CAPACITY TEST OPERATING TEMP. STORING TEMP. HELMET MATERIAL
|
1 / 1 / 1 / 1
97 x 62 mm (3.82" x 2.44") 133 x 114 x 9 mm (5.25" x 4.50" x 0.35") 4 DIN 3.5 Variable Shade 5 ~ 9/9 ~ 13 internal, Variable Shade Automatic On/Off Low ~ High, by infinitely dial knob Up to Shade DIN16 at all times Solar cell. Battery replaceable, 2 × CR2450 lithium battery 1/25,000 s. from Light to Dark 0.1 ~ 1.0 s by infinitely dial knob ≥ 2 amps (DC); ≥ 2 amps (AC) Yes Yes Yes -10 °C ~ +55 °C (14 °F ~ 131 °F) -20 °C ~ +70 °C (- 4 °F ~ 158 °F) High Impact Resistance Nylon |
Flip-up design - Easy lift up for grinding function, suiting welding / cutting / grinding mode.
Large view for grinding - 20 x 12 cm area, large and curved transparent grinding anti-fog lens.
Superior lens-technology - Highest optical class 1 / 1 / 1 / 1, offering best vision experience and welding efficiency.
Save-power function- Solar cell combined with replaceable battery, greatly increase service life.
High impact resistance - High tenacity shell material, passing EN175 B and ANSI Z87 + impact test under highest level.
Pivot headgear - Adjustable pivot design, well-balanced design, maximum comfort level, lock function in upright state.
Side window - Shade 5 lens on both sides, enhance surrounding vision, safer and securer.
