MIG/MAG INVERTER – MASTER M

MASTER M

Master M is a premium and compact MIG/MAG welding machine with synergic and pulse MIG welding model options. It elevates industrial welding performance, ensuring outstanding welding quality. Designed with professional welders, Master M makes everyday welding tasks effortless and fast.

Digital arc control, fast set-up techniques, and excellent power-to-weight set new standards for weld quality and work-based efficiency, boosting welding production. Choose from three class-leading models in the compact MIG welding machine category (353, 355, or 358), featuring alternative manual, synergic (Auto), and pulse (Auto Pulse) welding options. Weld with gas-cooled guns or select the optional Master M cooling system for an integrated liquid-cooled package that maximizes the 350A 40% ED welding power and enables more extended welding periods.

Interested in a Product?

  • Red Dot Product Design Award winner 2023
  • Versatile process selection for industrial welding: Manual, 1-MIG, Pulse MIG, DC TIG, and stick welding (MMA)
  • Welding programs incl. Fe, Ss, Al, CuSi, CuAl, Fe Metal, Fe Rutil, FC-CrNiMo materials
  • MAX and Wise welding processes for challenging steel, stainless steel, and aluminum welding applications
  • Cobot-ready welding machine, fast and easy setup with a Digital Connectivity Module and Kemppi Cobotics app
  • Weld Assist establishes guidance for welding parameters
  • Self-charging LED work lights improve work safety
  • Safe-lift grab handle for safe lifting
  • Two and four-wheel carriage options for easy movement
  • SuperSnake GTX sub-feeder enables maximum reach in challenging welding sites
  • Track and record arc-on time and welding parameters with integrated WeldEye ArcVision
  • Digital WPS feature ensures that welding procedure specifications are always accurately followed

synergic and pulse MIG welding

DescriptionValue
Mains connection voltage380...460 V ±10 %
Mains connection phases3~50/60 Hz
Mains connection cable typeH07RN-F
Mains connection cable size4 mm²
Maximum supply current [I1max]17.1 A...21.3 A
Effective supply current [I1eff]10.8 A...13.5 A
Rated maximum input power [S1max]14 kVA
Mains fuse16 A
Idle state power consumption [P1idle]18 W
No-load state power consumption (MMA), power save18 W
No-load state power consumption (MMA), fans ON119 W
No-load voltage [U0]55 V...69 V
Open circuit voltage [Uav]53 V...64 V
Output, duty cycle % at rated max. current, MIG40 %
Output at +40 °C, rated max current, MIG350 A
Output at +40 °C, 60% MIG280 A
Output at +40 °C, 100% MIG220 A
Output range, MIG15 A / 10 V ... 350 A / 45 V
Output range, TIG15 A / 1 V ... 350 A / 45 V
Output range, MMA15 A / 10 V ... 330 A / 45 V
Voltage adjustment range, MIG10 V...40 V
VRD voltage24 V
Power factor at rated maximum current [λ]0.91
Efficiency at rated maximum current [η]87 %
EMC classA
Minimum short-circuit power of supply network [Ssc]2.4 MVA
Voltage supply for auxiliary devices12 V
Voltage supply for cooling unit24 V, 380...460 V
Welding connection typeEuro
Wire feed mechanism4-roll, Single-motor
Diameter of feed rolls32 mm
Filler wire diameter, Fe0.8 mm...1.2 mm
Filler wire diameter, Ss0.8 mm...1.2 mm
Filler wire diameter, MC/FC0.8 mm...1.2 mm
Filler wire diameter, Al0.8 mm...1.2 mm
Wire feed speed0.5 m/min...25 m/min
Maximum wire spool weight20 kg
Maximum wire spool diameter300 mm
Maximum shielding gas pressure0.5 MPa
Control panel, modelCustom LCD
Control panel, displayColor LCD
Control panel, controls2 control knobs, Push buttons
Control panel, type of installationBuilt-in
Control panel, input voltage (DC)12 V
Wired communication typeCAN bus
Operating temperature-20 °C...40 °C
Storage temperature-40 °C...60 °C
Recommended minimum generator power [Sgen]20 kVA
LED battery type and voltageSAMSUNG SDI (INR18650-26J; 3,6 V; 2600 mAh); LG CHEM (ICR18650HE4; 3,6 V; 2500 mAh)
Degree of protection (fully installed)IP23S
External dimensions, length602 mm
External dimensions, width298 mm
External dimensions, height447 mm
Weight without accessories27 kg
StandardsIEC 60974-1, -10
